Airport Pump Station New Generator Pad - Peterborough
Parsways completed the temporary structural engineering and shop drawing design for a new generator pad at the airport pump station. The scope involved designing the temporary formwork and shoring required to safely support the concrete pour.
The engineering team focused on creating a sturdy containment system that handles the weight and pressure of freshly poured concrete. This design follows local building codes and safety standards to prevent shifting or failure on-site.
Location: Peterborough, Ontario
Completion: May 2026
Sector: Industrial
1. The Challenge
The project required temporary formwork capable of safely holding heavy concrete pressures during construction.
Concrete Pressure Control:
The wooden forms had to withstand high liquid pressure up to a maximum wall height of 1250 mm.
Structural Site Stability:
The framework needed to stay perfectly upright and resist unexpected impacts, wind, and equipment bumps.
Shape Preservation:
The system required precise bracing to maintain exact footing widths and prevent the wood from shifting.
2. The Engineering Solution
Parsways designed a reliable temporary framing and shoring system following Ontario safety guidelines.
a) Framing Layout:
The solution specified thick plywood sheathing supported by vertical studs and double wooden backings.
b) Heavy-Duty Wall Ties:
High-capacity wall ties and strong wood struts were integrated to lock the opposing form walls together.
c) Ground Bracing:
The framework was stabilized using diagonal bracing firmly anchored into the ground to keep everything straight.
3. The Outcome
The project resulted in a fully stamped, permit-ready structural package accepted by the local authority. The design minimized construction risk during excavation, provided clear sequencing for site execution, and ensured long-term structural stability in full compliance with OBC 2024 and applicable CSA standards.
